Orlock™ 6.4mm Steel Protruding Head Rivet

Orlock™ 6.4mm Steel Protruding Head Rivet

ORL-238692

Secure your structures with Orlockâ„¢ steel rivets. High strength, double-locking system for safety. Ideal for automotive and industrial applications.

$39.99
$39.99
Sale

Initiate Order

Orlock™ 6.4mm Steel Protruding Head Rivet

Orlock™ 6.4mm Steel Protruding Head Rivet

$39.99

Quantity: 1

Claim Your Seller Account

Orlock™ 6.4mm Steel Protruding Head Rivet

Orlock™ 6.4mm Steel Protruding Head Rivet

$39.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Orlock™ 6.4mm Steel Protruding Head Rivet is a durable and reliable structural fastener designed for various applications. With a double-locking system, it ensures a secure joint, ideal for seats, trailer frames, hinges, and more. Made of low carbon steel with Zinc Plated Chromium finish, it offers high shear and tensile forces, meeting stringent quality standards for automotive and construction use.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Applications Automotive Application
Steering Wheel MechanismSafety, and quality products are part of Ornit's DNA. The Orlock™ with its unique capabilities, and featuring a double locking system was selected to provide peace of mind to countless drivers worldwide.SeatingThe Orlock™ is a structural fastener, featuring a unique double-locking system that enables the rivet to safely secure the seats.
Nominal Dimensions Body Length
9.0 mm | 0.354 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.259 to 0.267 in
Nominal Dimensions Head Diameter
13.0 mm | 0.512 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
3.5 mm | 0.138 in
Nominal Dimensions Minimum Grip Range
1.5 mm | 0.059 in
Nominal Forces Nominal Shear Force
700 kgf | 1540 lbf
Nominal Forces Nominal Tensile Force
660 kgf | 1452 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Orlock™ | Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Protruding
Technical Specs Mandrel Finish
Zinc Coated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
