Orlockâ„¢ 6.4mm X Large Head Steel Rivet

Orlockâ„¢ 6.4mm X Large Head Steel Rivet

ORL-522a7b

Durable and secure Orlockâ„¢ 6.4mm X Large Head Rivet for high shear and tensile forces in automotive applications.

$49.99
$49.99
Sale

Initiate Order

Orlockâ„¢ 6.4mm X Large Head Steel Rivet

Orlockâ„¢ 6.4mm X Large Head Steel Rivet

$49.99

Quantity: 1

Claim Your Seller Account

Orlockâ„¢ 6.4mm X Large Head Steel Rivet

Orlockâ„¢ 6.4mm X Large Head Steel Rivet

$49.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Orlockâ„¢ 6.4mm X Large Head Rivet is a structural fastener designed for exceptional shear and tensile forces, ideal for securing seats, frames, hinges, and more. With a double-locking system, vibration-resistant joint, and high-quality materials such as low carbon steel and zinc plating, this rivet ensures durability and safety in automotive applications. Its precise dimensions and impressive nominal forces make it a reliable choice for various industrial uses.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Applications Automotive Application
Steering Wheel MechanismSafety, and quality products are part of Ornit's DNA. The Orlock™ with its unique capabilities, and featuring a double-locking system was selected to provide peace of mind to countless drivers worldwide.SeatingThe Orlock™ is a structural fastener, featuring a unique double-locking system that enables the rivet to safely secure the seats.
Nominal Dimensions Body Length
16.5 mm | 0.650 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.259 to 0.267 in
Nominal Dimensions Head Diameter
19.0 mm | 0.748 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
10.8 mm | 0.425 in
Nominal Dimensions Minimum Grip Range
8.8 mm | 0.346 in
Nominal Forces Nominal Shear Force
1140 kgf | 2508 lbf
Nominal Forces Nominal Tensile Force
660 kgf | 1452 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Orlock™ | Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
