Orlock™ Aluminum Protruding Head Rivet - 6.4mm x 20.5mm

Orlock™ Aluminum Protruding Head Rivet - 6.4mm x 20.5mm

ORL-ace2ea

Secure high-pressure joints with the Orlock™ Aluminum Protruding Head Rivet - 6.4mm x 20.5mm. Engineered for durability and precision, ideal for various joint applications.

$39.99
$39.99
Sale

Initiate Order

Orlock™ Aluminum Protruding Head Rivet - 6.4mm x 20.5mm

Orlock™ Aluminum Protruding Head Rivet - 6.4mm x 20.5mm

$39.99

Quantity: 1

Claim Your Seller Account

Orlock™ Aluminum Protruding Head Rivet - 6.4mm x 20.5mm

Orlock™ Aluminum Protruding Head Rivet - 6.4mm x 20.5mm

$39.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Orlock™ 6.4mm Aluminum Protruding Head Rivet is engineered to deliver high shear and tensile forces, ensuring a secure and vibration-resistant joint. With a body made of Aluminum Alloy (ALmg 2.5) and a protruding head design, this rivet is ideal for a variety of joint applications. Its precise dimensions, such as 6.4mm diameter and 20.5mm body length, ensure a reliable and durable fastening solution. Compliant with industry standards, including Federal/DoD procurement standards and GSA requirements, this rivet is a trusted choice for applications requiring superior performance and reliability.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Nominal Dimensions Body Length
20.5 mm | 0.807 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.259 to 0.267 in
Nominal Dimensions Head Diameter
13.0 mm | 0.512 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
14.8 mm | 0.583 in
Nominal Dimensions Minimum Grip Range
12.8 mm | 0.504 in
Nominal Forces Nominal Shear Force
500 kgf | 1100 lbf
Nominal Forces Nominal Tensile Force
350 kgf | 770 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 2.5)
Technical Specs Brands
Orlock™ | Ornit
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Protruding
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Aluminum Alloy 7075 or Equivalent
