Orlockâ¢ Aluminum Protruding Head Rivet - 9.8mm x 17.5mm

Name: Orlockâ¢ Aluminum Protruding Head Rivet - 9.8mm x 17.5mm
Brand: Ornit USA
SKU: ORL-38db7b
Price: 29.99 USD
Availability: OutOfStock

SKU:ORL-38db7b

Premium Orlockâ„¢ Aluminum Rivet for strong, vibration-resistant joints. 9.8mm x 17.5mm.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Orlockâ„¢ Aluminum Protruding Head Rivet is a high-quality structural fastener designed for maximum joint strength and vibration resistance. With a body length of 17.5mm and a 9.8mm diameter, this rivet ensures secure and durable connections. Crafted from premium Aluminum Alloy, it meets stringent quality standards, offering exceptional shear force of 900 kgf and tensile force of 1320 kgf. Ideal for various applications, this rivet is a reliable choice for both consumer and institutional buyers seeking top-tier fastening solutions.

Product Specifications

Nominal Dimensions Body Length

17.5 mm | 0.689 in

Nominal Dimensions Diameter

9.8 mm | 3/8 in

Nominal Dimensions Drillhole Size

10.0 to 10.4 mm | 0.394 to 0.409 in

Nominal Dimensions Head Diameter

19.5 mm | 0.768 in

Nominal Dimensions Head Thickness

4.2 mm | 0.165 in

Nominal Dimensions Mandrel Diameter

6.00 mm | 0.236 in

Nominal Dimensions Maximum Grip Range

9.0 mm | 0.354 in

Nominal Dimensions Minimum Grip Range

6.0 mm | 0.236 in

Nominal Forces Nominal Shear Force

900 kgf | 1980 lbf

Nominal Forces Nominal Tensile Force

1320 kgf | 600 lbf

Technical Specs Body Finish

Natural

Technical Specs Body Material

Aluminum Alloy (ALmg 2.5)

Technical Specs Brands

Orlockâ¢ | Ornit

Technical Specs Carton Quantity

500

Technical Specs Head Style

Protruding

Technical Specs Mandrel Finish

Natural

Technical Specs Mandrel Material

Aluminum Alloy 7075 or Equivalent
