Orlock⢠Aluminum X-Large Head Rivet, 20.5mm Body Length
Orlock⢠Aluminum X-Large Head Rivet, 20.5mm Body Length
SKU:ORL-87ab6d
Enhance joint integrity with Orlockâ„¢ Aluminum X-Large Head Rivet for secure, vibration-resistant joints with high shear and tensile forces.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Orlock⢠Aluminum X-Large Head Rivet, 20.5mm Body Length
$59.99
Quantity: 1
Claim Your Seller Account
Orlock⢠Aluminum X-Large Head Rivet, 20.5mm Body Length
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your joint applications with the Orlockâ„¢ 20.5mm Body Length Aluminum X-Large Head Rivet. Made from high-quality Aluminum Alloy, this structural fastener provides exceptional shear and tensile forces for secure, vibration-resistant joints. With a nominal shear force of 500 kgf and a nominal tensile force of 350 kgf, this rivet ensures lasting durability and reliability in various applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
20.5 mm | 0.807 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.8 mm | 0.167 to 0.172 in
Nominal Dimensions Head Diameter
19.0 mm | 0.748 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
14.8 mm | 0.583 in
Nominal Dimensions Minimum Grip Range
12.8 mm | 0.504 in
Nominal Forces Nominal Shear Force
500 kgf | 1100 lbf
Nominal Forces Nominal Tensile Force
350 kgf | 770 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 2.5)
Technical Specs Brands
Orlock⢠| Ornit
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Aluminum Alloy (ALmg 5.0 - 6.0) or Equivalent
