Orlock™ Stainless Steel Protruding Head Rivet: 4.8mm x 16.5mm

Orlock™ Stainless Steel Protruding Head Rivet: 4.8mm x 16.5mm

ORL-e0a905

Top choice for global trailer manufacturers, the Orlockâ„¢ Stainless Steel Protruding Head Rivet offers unmatched durability and strength in severe conditions.

$89.99
$89.99
Sale

Initiate Order

Orlock™ Stainless Steel Protruding Head Rivet: 4.8mm x 16.5mm

Orlock™ Stainless Steel Protruding Head Rivet: 4.8mm x 16.5mm

$89.99

Quantity: 1

Claim Your Seller Account

Orlock™ Stainless Steel Protruding Head Rivet: 4.8mm x 16.5mm

Orlock™ Stainless Steel Protruding Head Rivet: 4.8mm x 16.5mm

$89.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Orlockâ„¢ 4.8mm Stainless Steel Protruding Head Rivet is a top choice for trailer manufacturers globally, ensuring a lasting and secure joint even in harsh climates. Made of AISI 304 stainless steel, it offers exceptional durability and resistance. With nominal shear force of 700kgf and tensile force of 510kgf, this rivet delivers reliability and strength. Compliant with stringent industry standards, including potential production in AISI 316, this rivet is a premium solution for demanding applications.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Nominal Dimensions Body Length
16.5 mm | 0.650 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 to 5.1 mm | 0.192 to 0.201 in
Nominal Dimensions Head Diameter
9.8 mm | 0.386 in
Nominal Dimensions Head Thickness
2.2 mm | 0.087 in
Nominal Dimensions Mandrel Diameter
3.02 mm | 0.119 in
Nominal Dimensions Maximum Grip Range
11.0 mm | 0.433 in
Nominal Dimensions Minimum Grip Range
8.5 mm | 0.335 in
Nominal Forces Nominal Shear Force
700 kgf | 1544 lbf
Nominal Forces Nominal Tensile Force
510 kgf | 1125 lbf
Note Note
Can be Produced with Austenitic Stainless Steel A4 - AISI 316
Technical Specs Body Finish
Natural
Technical Specs Body Material
Austenitic Stainless Steel American Iron and Steel Institute (AISI) 304
Technical Specs Brands
Orlock™ | Ornit
Technical Specs Carton Quantity
3000
Technical Specs Head Style
Protruding
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Austenitic Stainless Steel 304
