Orlock™ Stainless Steel Protruding Head Rivet - 4.8mm x 19.0mm

Orlock™ Stainless Steel Protruding Head Rivet - 4.8mm x 19.0mm

ORL-cceee4

Durable Stainless Steel Protruding Head Rivet for secure joints in severe climates. AISI 304 material, meets industry standards.

$129.99
$129.99
Sale

Initiate Order

Orlock™ Stainless Steel Protruding Head Rivet - 4.8mm x 19.0mm

Orlock™ Stainless Steel Protruding Head Rivet - 4.8mm x 19.0mm

$129.99

Quantity: 1

Claim Your Seller Account

Orlock™ Stainless Steel Protruding Head Rivet - 4.8mm x 19.0mm

Orlock™ Stainless Steel Protruding Head Rivet - 4.8mm x 19.0mm

$129.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Orlockâ„¢ Stainless Steel Protruding Head Rivet is a top choice for trailer manufacturers globally, providing a permanent and secure joint in extreme weather. With a body made of AISI 304 Austenitic Stainless Steel and a Protruding Head design, it offers exceptional durability. This rivet meets rigorous industry standards and is also available in AISI 316, ensuring reliability in demanding applications.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Nominal Dimensions Body Length
19.0 mm | 0.748 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 to 5.1 mm | 0.192 to 0.201 in
Nominal Dimensions Head Diameter
9.8 mm | 0.386 in
Nominal Dimensions Head Thickness
2.2 mm | 0.087 in
Nominal Dimensions Mandrel Diameter
3.02 mm | 0.119 in
Nominal Dimensions Maximum Grip Range
13.0 mm | 0.512 in
Nominal Dimensions Minimum Grip Range
11.0 mm | 0.433 in
Nominal Forces Nominal Shear Force
700 kgf | 1544 lbf
Nominal Forces Nominal Tensile Force
510 kgf | 1125 lbf
Note Note
Can be Produced with Austenitic Stainless Steel A4 - AISI 316
Technical Specs Body Finish
Natural
Technical Specs Body Material
Austenitic Stainless Steel American Iron and Steel Institute (AISI) 304
Technical Specs Brands
Orlock™ | Ornit
Technical Specs Carton Quantity
3000
Technical Specs Head Style
Protruding
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Austenitic Stainless Steel 304
