Orlock™ Stainless Steel Protruding Head Rivet, 6.4mm x 14.5mm

Orlock™ Stainless Steel Protruding Head Rivet, 6.4mm x 14.5mm

ORL-521c58

Premium Orlock™ stainless steel rivet, 6.4mm diameter, 14.5mm body length, ideal for trailers and solar frames.

$69.99
$69.99
Sale

Initiate Order

Orlock™ Stainless Steel Protruding Head Rivet, 6.4mm x 14.5mm

Orlock™ Stainless Steel Protruding Head Rivet, 6.4mm x 14.5mm

$69.99

Quantity: 1

Claim Your Seller Account

Orlock™ Stainless Steel Protruding Head Rivet, 6.4mm x 14.5mm

Orlock™ Stainless Steel Protruding Head Rivet, 6.4mm x 14.5mm

$69.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Orlock™ Stainless Steel Protruding Head Rivet is a premium fastener ideal for trailer manufacturing and solar applications. Made of high-quality AISI 304 stainless steel, it offers a secure joint in extreme weather conditions, meeting rigorous industry standards. With impressive shear and tensile forces, this rivet ensures durability and reliability for your projects.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Applications Renewable Energy Application
Solar FramesThe Orlock™ Stainless Steel is commonly used in a variety of solar applications worldwide. This stainless steel rivet provides a permanent, secure joint in the most severe climate conditions. Also available in 316.
Nominal Dimensions Body Length
14.5 mm | 0.571 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.6 to 6.7 mm | 0.260 to 0.264 in
Nominal Dimensions Head Diameter
13.0 mm | 0.512 in
Nominal Dimensions Head Thickness
3.0 mm | 0.118 in
Nominal Dimensions Mandrel Diameter
4.17 mm | 0.164 in
Nominal Dimensions Maximum Grip Range
8.5 mm | 0.335 in
Nominal Dimensions Minimum Grip Range
5.0 mm | 0.197 in
Nominal Forces Nominal Shear Force
1480 kgf | 3263 lbf
Nominal Forces Nominal Tensile Force
850 kgf | 1874 lbf
Note Note
Can be Produced with Austenitic Stainless Steel A4 - AISI 316
Technical Specs Body Finish
Natural
Technical Specs Body Material
Austenitic Stainless Steel American Iron and Steel Institute (AISI) 304
Technical Specs Brands
Orlock™ | Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Protruding
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Austenitic Stainless Steel 304
