Ornit 2.9mm x 16.0mm Open End Dome Blind Rivet
Ornit 2.9mm x 16.0mm Open End Dome Blind Rivet
SKU:OPE-71961c
Premium Ornit 2.9mm x 16.0mm Dome Blind Rivet for secure and durable fastening in industrial applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Ornit 2.9mm x 16.0mm Open End Dome Blind Rivet
$29.99
Quantity: 1
Claim Your Seller Account
Ornit 2.9mm x 16.0mm Open End Dome Blind Rivet
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 2.9mm Diameter and 16.0mm Body Length Open End Dome Blind Rivet is a high-quality fastening solution designed for heavy-duty applications. Constructed from Aluminum Alloy (AA 5052), this rivet offers exceptional strength and durability. The zinc-plated chromium mandrel ensures secure fastening, meeting stringent industrial standards for reliability. With a nominal shear force of 70 kgf and a nominal tensile force of 85 kgf, this rivet guarantees robust performance under extreme conditions.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
16.0 mm | 0.630 in
Nominal Dimensions Diameter
2.9 mm
Nominal Dimensions Drillhole Size
3.1 mm | 0.122 in
Nominal Dimensions Head Diameter
6.3 mm | 0.248 in
Nominal Dimensions Head Thickness
0.90 mm | 0.035 in
Nominal Dimensions Mandrel Diameter
1.81 mm | 0.071 in
Nominal Dimensions Maximum Grip Range
13.0 mm | 0.512 in
Nominal Dimensions Minimum Grip Range
11.0 mm | 0.433 in
Nominal Forces Nominal Shear Force
70 kgf | 154 lbf
Nominal Forces Nominal Tensile Force
85 kgf | 187 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
9000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
