Ornit 3.2mm Dome Blind Rivet
Ornit 3.2mm Dome Blind Rivet
SKU:OPE-52d748
High-strength 3.2mm Dome Blind Rivet for secure and reliable fastening. Aluminum Alloy body with zinc-plated steel mandrel.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Ornit 3.2mm Dome Blind Rivet
$39.99
Quantity: 1
Claim Your Seller Account
Ornit 3.2mm Dome Blind Rivet
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your fastening solutions with the Ornit 3.2mm Diameter Dome Blind Rivet. Made of Aluminum Alloy to AA 5052 with a zinc-plated low carbon steel mandrel, this rivet offers exceptional shear and tensile strength. With a grip range of 10.5mm to 12.5mm, it ensures secure and reliable fastening. Ideal for a wide range of applications requiring precision and durability.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
16.0 mm | 0.630 in
Nominal Dimensions Diameter
3.2 mm
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
6.3 mm | 0.248 in
Nominal Dimensions Head Thickness
0.90 mm | 0.035 in
Nominal Dimensions Mandrel Diameter
1.81 mm | 0.071 in
Nominal Dimensions Maximum Grip Range
12.5 mm | 0.492 in
Nominal Dimensions Minimum Grip Range
10.5 mm | 0.413 in
Nominal Forces Nominal Shear Force
75 kgf | 165 lbf
Nominal Forces Nominal Tensile Force
100 kgf | 220 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
7000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
