Ornit 3.2mm Dome Blind Rivet (20mm Body Length)
Ornit 3.2mm Dome Blind Rivet (20mm Body Length)
SKU:OPE-17503c
Premium Ornit 3.2mm Dome Blind Rivet, Aluminum Alloy, Zinc Plated Low Carbon Steel Mandrel, Ideal for Secure Fastening
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Ornit 3.2mm Dome Blind Rivet (20mm Body Length)
$29.99
Quantity: 1
Claim Your Seller Account
Ornit 3.2mm Dome Blind Rivet (20mm Body Length)
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 3.2mm Dome Blind Rivet with a 20mm body length is engineered for superior fastening performance. Constructed from aluminum alloy to AA 5052 with a natural finish, this rivet offers exceptional strength and corrosion resistance. Its low carbon steel SAE 1006-1022 mandrel, zinc plated chromium VI free finish, and precise dimensions ensure reliable shear and tensile forces. Ideal for a wide range of applications requiring secure and durable fastening solutions.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
20.0 mm | 0.787 in
Nominal Dimensions Diameter
3.2 mm
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
6.3 mm | 0.248 in
Nominal Dimensions Head Thickness
0.90 mm | 0.035 in
Nominal Dimensions Mandrel Diameter
1.81 mm | 0.071 in
Nominal Dimensions Maximum Grip Range
16.5 mm | 0.650 in
Nominal Dimensions Minimum Grip Range
14.5 mm | 0.571 in
Nominal Forces Nominal Shear Force
75 kgf | 165 lbf
Nominal Forces Nominal Tensile Force
100 kgf | 220 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
6000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
