Ornit 3.2mm Large Blind Rivet - Aluminum Alloy Body
Ornit 3.2mm Large Blind Rivet - Aluminum Alloy Body
SKU:OPE-af32f7
High-quality Ornit 3.2mm Large Blind Rivet for heavy-duty applications, featuring Aluminum Alloy body and Large head style.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Ornit 3.2mm Large Blind Rivet - Aluminum Alloy Body
$59.99
Quantity: 1
Claim Your Seller Account
Ornit 3.2mm Large Blind Rivet - Aluminum Alloy Body
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 3.2mm Large Blind Rivet features a 10.0mm body length and is crafted from high-quality Aluminum Alloy to AA 5052 standards. With a head style of Large and a Zinc Plated Chromium (Cr) VI Free mandrel, this rivet ensures reliable performance. It offers a nominal shear force of 75 kgf and a nominal tensile force of 100 kgf, making it ideal for heavy-duty applications. Trust in the durability and precision of Ornit for your riveting needs.
Product Specifications
Nominal Dimensions Body Length
10.0 mm | 0.394 in
Nominal Dimensions Diameter
3.2 mm
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
9.5 mm | 0.374 in
Nominal Dimensions Head Thickness
1.20 mm | 0.047 in
Nominal Dimensions Mandrel Diameter
1.81 mm | 0.71 in
Nominal Dimensions Maximum Grip Range
6.5 mm | 0.256 in
Nominal Dimensions Minimum Grip Range
4.5 mm | 0.177 in
Nominal Forces Nominal Shear Force
75 kgf | 165 lbf
Nominal Forces Nominal Tensile Force
100 kgf | 220 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
8000
Technical Specs Head Style
Large
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
