Ornit 3.2mm Open End Dome Blind Rivet
Ornit 3.2mm Open End Dome Blind Rivet
SKU:OPE-fe3f1e
Premium Ornit 3.2mm Dome Rivet for secure and durable fastening. Ideal for various applications.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Ornit 3.2mm Open End Dome Blind Rivet
$129.99
Quantity: 1
Claim Your Seller Account
Ornit 3.2mm Open End Dome Blind Rivet
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 3.2mm Open End Dome Blind Rivet is a high-quality fastening solution ideal for various applications. Manufactured with Aluminum Alloy and Low Carbon Steel, it offers exceptional durability and corrosion resistance. With a nominal shear force of 75kgf and a tensile force of 100kgf, it ensures reliable and secure fastening. The rivet's precise dimensions and grip range of 8.5mm to 10.5mm make it suitable for a wide range of projects, meeting stringent industry standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
14.0 mm | 0.551 in
Nominal Dimensions Diameter
3.2 mm
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
6.3 mm | 0.248 in
Nominal Dimensions Head Thickness
0.90 mm | 0.035 in
Nominal Dimensions Mandrel Diameter
1.81 mm | 0.071 in
Nominal Dimensions Maximum Grip Range
10.5 mm | 0.413 in
Nominal Dimensions Minimum Grip Range
8.5 mm | 0.335 in
Nominal Forces Nominal Shear Force
75 kgf | 165 lbf
Nominal Forces Nominal Tensile Force
100 kgf | 220 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
8000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
