Ornit 3.2mm x 10.0mm Closed End Blind Rivet
Ornit 3.2mm x 10.0mm Closed End Blind Rivet
SKU:CLO-0ccc03
Upgrade your projects with the Ornit 3.2mm x 10.0mm Closed End Blind Rivet for strong, reliable fastening. Meet high standards with Ornit's quality and performance.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Ornit 3.2mm x 10.0mm Closed End Blind Rivet
$29.99
Quantity: 1
Claim Your Seller Account
Ornit 3.2mm x 10.0mm Closed End Blind Rivet
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your riveting projects with the Ornit 3.2mm Diameter and 10.0mm Body Length Closed End Blind Rivet. Crafted from Aluminum Alloy (AA 5052) with a low carbon steel SAE 1006-1022 mandrel, these rivets ensure superior strength and durability. With a grip range between 3.5mm to 5.0mm, they offer reliable fastening for various applications. Meet high standards with a nominal shear force of 102 kgf and a nominal tensile force of 133 kgf. Trusted for quality and performance, Ornit rivets are the ideal choice for your industrial needs.
Product Specifications
Nominal Dimensions Body Length
10.0 mm | 0.394 in
Nominal Dimensions Diameter
3.2 mm
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
6 mm | 0.236 in
Nominal Dimensions Head Thickness
1.40 mm | 0.055 in
Nominal Dimensions Mandrel Diameter
1.7 mm | 0.067 in
Nominal Dimensions Maximum Grip Range
5.0 mm | 0.197 in
Nominal Dimensions Minimum Grip Range
3.5 mm | 0.138 in
Nominal Forces Nominal Shear Force
102 kgf | 224.4 lbf
Nominal Forces Nominal Tensile Force
133 kgf | 292.6 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
8000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
