Ornit 3.2mm x 10.5mm Closed End Blind Rivet
Ornit 3.2mm x 10.5mm Closed End Blind Rivet
SKU:CLO-66c5de
Ornit 3.2mm x 10.5mm Closed End Blind Rivet for secure and durable fastening applications.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Ornit 3.2mm x 10.5mm Closed End Blind Rivet
$45.99
Quantity: 1
Claim Your Seller Account
Ornit 3.2mm x 10.5mm Closed End Blind Rivet
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your fastening applications with the Ornit 3.2mm Diameter and 10.5mm Body Length Closed End Blind Rivet. Crafted from Aluminum Alloy to AA 5052 standards, with a Black Phosphate finished Low Carbon Steel SAE 1006-1022 mandrel, this rivet offers exceptional shear and tensile forces. With a head diameter of 6mm and a minimum grip range of 5.0mm, it ensures secure and reliable fastening. Ideal for various industries, meeting strict procurement standards with precision and durability.
Product Specifications
Nominal Dimensions Body Length
10.5 mm | 0.413 in
Nominal Dimensions Diameter
3.2 mm
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
6 mm | 0.236 in
Nominal Dimensions Head Thickness
1.40 mm | 0.055 in
Nominal Dimensions Mandrel Diameter
1.7 mm | 0.067 in
Nominal Dimensions Maximum Grip Range
6.5 mm | 0.256 in
Nominal Dimensions Minimum Grip Range
5.0 mm | 0.197 in
Nominal Forces Nominal Shear Force
102 kgf | 224.4 lbf
Nominal Forces Nominal Tensile Force
133 kgf | 292.6 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
6000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
