Ornit 3.2mm x 6.0mm Closed End Blind Rivet
Ornit 3.2mm x 6.0mm Closed End Blind Rivet
SKU:CLO-3aef96
High-strength Ornit 3.2mm x 6.0mm Closed End Blind Rivet, perfect for secure and durable fastening.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Ornit 3.2mm x 6.0mm Closed End Blind Rivet
$39.99
Quantity: 1
Claim Your Seller Account
Ornit 3.2mm x 6.0mm Closed End Blind Rivet
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 3.2mm Diameter and 6.0mm Body Length Closed End Blind Rivet offers exceptional reliability in fastening applications. Constructed with Aluminum Alloy body and Low Carbon Steel mandrel, it ensures corrosion resistance and high tensile strength. With a nominal shear force of 102 kgf and nominal tensile force of 133 kgf, it guarantees secure and durable joints. Ideal for industrial, automotive, and construction projects requiring precision fastening.
Product Specifications
Nominal Dimensions Body Length
6.0 mm | 0.236 in
Nominal Dimensions Diameter
3.2 mm
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
6 mm | 0.236 in
Nominal Dimensions Head Thickness
1.40 mm | 0.055 in
Nominal Dimensions Mandrel Diameter
1.7 mm | 0.067 in
Nominal Dimensions Maximum Grip Range
2.0 mm | 0.079 in
Nominal Dimensions Minimum Grip Range
0.5 mm | 0.020 in
Nominal Forces Nominal Shear Force
102 kgf | 224.4 lbf
Nominal Forces Nominal Tensile Force
133 kgf | 292.6 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
10000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
