Ornit 4.0mm Dome Blind Rivet
Ornit 4.0mm Dome Blind Rivet
SKU:OPE-980988
Secure and reliable Ornit 4.0mm Dome Blind Rivet for versatile fastening applications. Compliant with top procurement standards.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Ornit 4.0mm Dome Blind Rivet
$49.99
Quantity: 1
Claim Your Seller Account
Ornit 4.0mm Dome Blind Rivet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.0mm Dome Blind Rivet is a versatile fastening solution crafted from Aluminum Alloy to AA 5052, featuring a zinc-plated chromium mandrel for enhanced durability. With a 22.0mm body length and nominal shear force of 100 kgf, this rivet ensures secure and reliable fastening in various applications. Compliant with Federal procurement standards and industry-specific certifications, this rivet meets the highest quality and safety requirements.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
22.0 mm | 0.866 in
Nominal Dimensions Diameter
4.0 mm
Nominal Dimensions Drillhole Size
4.1 mm | 0.161 in
Nominal Dimensions Head Diameter
7.8 mm | 0.307 in
Nominal Dimensions Head Thickness
1.15 mm | 0.045 in
Nominal Dimensions Mandrel Diameter
2.31 mm | 0.091 in
Nominal Dimensions Maximum Grip Range
17.5 mm | 0.689 in
Nominal Dimensions Minimum Grip Range
15.5 mm | 0.610 in
Nominal Forces Nominal Shear Force
100 kgf | 220 lbf
Nominal Forces Nominal Tensile Force
160 kgf | 352 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
