Ornit 4.0mm Open End Dome Blind Rivet
Ornit 4.0mm Open End Dome Blind Rivet
SKU:OPE-51d325
High-strength Ornit 4.0mm Dome Blind Rivet for secure fastening in varied applications.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Ornit 4.0mm Open End Dome Blind Rivet
$39.99
Quantity: 1
Claim Your Seller Account
Ornit 4.0mm Open End Dome Blind Rivet
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your fastening solutions with the Ornit 4.0mm Open End Dome Blind Rivet. Crafted from high-quality Aluminum Alloy and Low Carbon Steel, this rivet ensures exceptional strength with a nominal shear force of 100 kgf and nominal tensile force of 160 kgf. With a body length of 10.0mm and precise dimensions, it offers a secure grip range of 3.5mm to 5.5mm. Ideal for a wide range of applications, this rivet meets stringent industry standards for durability and performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
10.0 mm | 0.394 in
Nominal Dimensions Diameter
4.0 mm
Nominal Dimensions Drillhole Size
4.1 mm | 0.161 in
Nominal Dimensions Head Diameter
7.8 mm | 0.307 in
Nominal Dimensions Head Thickness
1.15 mm | 0.045 in
Nominal Dimensions Mandrel Diameter
2.31 mm | 0.091 in
Nominal Dimensions Maximum Grip Range
5.5 mm | 0.217 in
Nominal Dimensions Minimum Grip Range
3.5 mm | 0.138 in
Nominal Forces Nominal Shear Force
100 kgf | 220 lbf
Nominal Forces Nominal Tensile Force
160 kgf | 352 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
7000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
