Ornit 4.0mm x 10.0mm Open End Peel Blind Rivet
Ornit 4.0mm x 10.0mm Open End Peel Blind Rivet
SKU:OPE-bdba6c
Premium Ornit 4.0mm x 10.0mm Open End Peel Blind Rivet - Durable, Reliable, Precise Fastening
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Ornit 4.0mm x 10.0mm Open End Peel Blind Rivet
$59.99
Quantity: 1
Claim Your Seller Account
Ornit 4.0mm x 10.0mm Open End Peel Blind Rivet
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.0mm Diameter and 10.0mm Body Length Open End Peel Blind Rivet is a high-quality fastening solution designed for durability and precision. Crafted from Aluminum Alloy (AA 5056/5154) with a Zinc Plated Chromium (Cr) VI Free Low Carbon Steel Mandrel, this rivet ensures reliable performance. With a nominal shear force of 150 kgf and a nominal tensile force of 185 kgf, it meets the most stringent industrial demands. The rivet's head style, body finish, and precise dimensions make it ideal for a wide range of applications, offering secure and efficient fastening.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
10.0 mm | 0.394 in
Nominal Dimensions Diameter
4.0 mm
Nominal Dimensions Drillhole Size
4.3 mm | 0.169 in
Nominal Dimensions Head Diameter
7.8 mm | 0.307 in
Nominal Dimensions Head Thickness
1.15 mm | 0.045 in
Nominal Dimensions Mandrel Diameter
2.31 mm | 0.091 in
Nominal Dimensions Maximum Grip Range
4.0 mm | 0.157 in
Nominal Dimensions Minimum Grip Range
2.0 mm | 0.079 in
Nominal Forces Nominal Shear Force
150 kgf | 330 lbf
Nominal Forces Nominal Tensile Force
185 kgf | 407 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (3.5-5.0 mg) to AA 5056 /5154
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
7000
Technical Specs Head Style
Peel
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
