Ornit 4.0mm x 12.0mm Open End Peel Blind Rivet
Ornit 4.0mm x 12.0mm Open End Peel Blind Rivet
SKU:OPE-8b5dfe
Ornit 4.0mm x 12.0mm Blind Rivet, Aluminum Alloy, Zinc Plated Steel Mandrel, High Force
Regular price
$35.99
Regular price
Sale price
$35.99
Unit price
per
Initiate Order
Ornit 4.0mm x 12.0mm Open End Peel Blind Rivet
$35.99
Quantity: 1
Claim Your Seller Account
Ornit 4.0mm x 12.0mm Open End Peel Blind Rivet
$35.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your fastening solutions with the Ornit 4.0mm Diameter and 12.0mm Body Length Open End Peel Blind Rivet. Crafted from Aluminum Alloy (AA 5056/5154) with a Zinc Plated Chromium VI-Free Low Carbon Steel mandrel, this rivet offers superior durability and corrosion resistance. With a Nominal Shear Force of 150kgf and Nominal Tensile Force of 185kgf, it ensures reliable performance. Perfect for various applications, this rivet meets Federal/DoD procurement standards and FAR compliance factors, making it ideal for institutional buyers seeking quality and adherence to regulations.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
12.0 mm | 0.472 in
Nominal Dimensions Diameter
4.0 mm
Nominal Dimensions Drillhole Size
4.3 mm | 0.169 in
Nominal Dimensions Head Diameter
7.8 mm | 0.307 in
Nominal Dimensions Head Thickness
1.15 mm | 0.045 in
Nominal Dimensions Mandrel Diameter
2.31 mm | 0.091 in
Nominal Dimensions Maximum Grip Range
6.0 mm | 0.236 in
Nominal Dimensions Minimum Grip Range
3.0 mm | 0.118 in
Nominal Forces Nominal Shear Force
150 kgf | 330 lbf
Nominal Forces Nominal Tensile Force
185 kgf | 407 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (3.5-5.0 mg) to AA 5056 /5154
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
6000
Technical Specs Head Style
Peel
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
