Ornit 4.0mm x 16mm Open End Peel Blind Rivet
Ornit 4.0mm x 16mm Open End Peel Blind Rivet
SKU:OPE-60682c
High-strength Ornit 4.0mm x 16mm Peel Blind Rivet for secure and durable fastenings in industrial applications.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Ornit 4.0mm x 16mm Open End Peel Blind Rivet
$45.99
Quantity: 1
Claim Your Seller Account
Ornit 4.0mm x 16mm Open End Peel Blind Rivet
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your fastening solutions with the Ornit 4.0mm Diameter and 16.0mm Body Length Open End Peel Blind Rivet. Constructed with Aluminum Alloy to AA 5056/5154, this rivet offers superior strength and durability. The zinc-plated Chromium VI Free mandrel ensures corrosion resistance, while meeting stringent industry standards. With a shear force of 150kgf and a tensile force of 185kgf, this rivet is ideal for heavy-duty applications. Achieve secure and long-lasting fastenings with this high-quality Ornit rivet.
Product Specifications
Nominal Dimensions Body Length
16.0 mm | 0.630 in
Nominal Dimensions Diameter
4.0 mm
Nominal Dimensions Drillhole Size
4.3 mm | 0.169 in
Nominal Dimensions Head Diameter
7.8 mm | 0.307 in
Nominal Dimensions Head Thickness
1.15 mm | 0.045 in
Nominal Dimensions Mandrel Diameter
2.31 mm | 0.091 in
Nominal Dimensions Maximum Grip Range
10.0 mm | 0.394 in
Nominal Dimensions Minimum Grip Range
6.0 mm | 0.236 in
Nominal Forces Nominal Shear Force
150 kgf | 330 lbf
Nominal Forces Nominal Tensile Force
185 kgf | 407 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (3.5-5.0 mg) to AA 5056 /5154
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
5000
Technical Specs Head Style
Peel
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
