Ornit 4.0mm x 30.0mm Dome Blind Rivet
Ornit 4.0mm x 30.0mm Dome Blind Rivet
SKU:OPE-cf91ac
High-quality Ornit 4.0mm Dome Blind Rivet for strong and reliable fastening, compliant with government standards.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Ornit 4.0mm x 30.0mm Dome Blind Rivet
$45.99
Quantity: 1
Claim Your Seller Account
Ornit 4.0mm x 30.0mm Dome Blind Rivet
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.0mm Diameter and 30.0mm Body Length Open End Dome Blind Rivet is a high-quality fastening solution designed for durability and strength. Made from Aluminum Alloy AA 5052 with a Zinc Plated Chromium VI Free Mandrel, this rivet offers excellent corrosion resistance and structural integrity. With a nominal shear force of 100 kgf and nominal tensile force of 160 kgf, it ensures reliable performance in various applications. Compliant with Federal/DoD procurement standards and industry certifications, this rivet meets the rigorous quality requirements of government and institutional buyers.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
30.0 mm | 1.18 in
Nominal Dimensions Diameter
4.0 mm
Nominal Dimensions Drillhole Size
4.1 mm | 0.161 in
Nominal Dimensions Head Diameter
7.8 mm | 0.307 in
Nominal Dimensions Head Thickness
1.15 mm | 0.045 in
Nominal Dimensions Mandrel Diameter
2.31 mm | 0.091 in
Nominal Dimensions Maximum Grip Range
25.5 mm | 1.00 in
Nominal Dimensions Minimum Grip Range
22.5 mm | 0.886 in
Nominal Forces Nominal Shear Force
100 kgf | 220 lbf
Nominal Forces Nominal Tensile Force
160 kgf | 352 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
3000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
