Ornit 4.8mm Closed End Blind Rivet, Aluminum Alloy Body, 18.0mm Length
Ornit 4.8mm Closed End Blind Rivet, Aluminum Alloy Body, 18.0mm Length
SKU:CLO-7fe30b
Ornit 4.8mm Closed End Blind Rivet for secure and durable fastening, ideal for various applications.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Ornit 4.8mm Closed End Blind Rivet, Aluminum Alloy Body, 18.0mm Length
$45.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm Closed End Blind Rivet, Aluminum Alloy Body, 18.0mm Length
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.8mm Closed End Blind Rivet is a durable fastening solution suitable for various applications. Constructed from Aluminum Alloy AA 5052 and featuring a low carbon steel SAE 1006-1022 mandrel with a black phosphate finish, this rivet ensures secure and long-lasting connections. With a nominal shear force of 224 kgf and a nominal tensile force of 316 kgf, it meets stringent industry standards for reliability and strength. The 4.8mm diameter and 18.0mm body length provide versatility for different grip ranges, making it ideal for both consumer and institutional buyers seeking top-quality blind rivets.
Product Specifications
Nominal Dimensions Body Length
18.0 mm | 0.709 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.5 mm | 0.374 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
2.6 mm | 0.102 in
Nominal Dimensions Maximum Grip Range
13.0 mm | 0.512 in
Nominal Dimensions Minimum Grip Range
11.0 mm | 0.433 in
Nominal Forces Nominal Shear Force
224 kgf | 492.8 lbf
Nominal Forces Nominal Tensile Force
316 kgf | 695.2 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
