Ornit 4.8mm Dia. Aluminum Blind Rivet
Ornit 4.8mm Dia. Aluminum Blind Rivet
SKU:CLO-e42016
Secure and durable Ornit 4.8mm Aluminum Blind Rivet with 224kgf shear force and 12.0mm body length.
Regular price
$89.99
Regular price
Sale price
$89.99
Unit price
per
Initiate Order
Ornit 4.8mm Dia. Aluminum Blind Rivet
$89.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm Dia. Aluminum Blind Rivet
$89.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.8mm Diameter Closed End Blind Rivet is a reliable fastening solution crafted from high-quality Aluminum Alloy AA 5052. With a body length of 12.0mm and impressive shear force of 224kgf, it offers secure and lasting connections. Its low carbon steel SAE 1006-1022 mandrel ensures consistent performance under tension, meeting rigorous industrial standards for structural integrity and durability.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
12.0 mm | 0.472 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.5 mm | 0.374 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
2.6 mm | 0.102 in
Nominal Dimensions Maximum Grip Range
8.0 mm | 0.315 in
Nominal Dimensions Minimum Grip Range
6.5 mm | 0.256 in
Nominal Forces Nominal Shear Force
224 kgf | 492.8 lbf
Nominal Forces Nominal Tensile Force
316 kgf | 695.2 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
