Ornit 4.8mm Dome Blind Rivet
Ornit 4.8mm Dome Blind Rivet
SKU:OPE-97afb0
Secure industrial fastening with Ornit 4.8mm Dome Blind Rivet, offering high strength and reliability for diverse applications.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Ornit 4.8mm Dome Blind Rivet
$49.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm Dome Blind Rivet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.8mm Dome Blind Rivet is designed for secure fastening in industrial applications. Constructed with Aluminum Alloy and a Zinc Plated Chromium Mandrel, it offers high shear and tensile forces. With a 25.0mm body length and a grip range of 17.0mm to 20.0mm, this rivet ensures sturdy connections. Suitable for various materials, this rivet meets stringent industry standards for reliability and performance.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
25.0 mm | 0.984 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.3 mm | 0.366 in
Nominal Dimensions Head Thickness
1.30 mm | 0.051 in
Nominal Dimensions Mandrel Diameter
2.61 mm | 0.103 in
Nominal Dimensions Maximum Grip Range
20.0 mm | 0.787 in
Nominal Dimensions Minimum Grip Range
17.0 mm | 0.669 in
Nominal Forces Nominal Shear Force
150 kgf | 330 lbf
Nominal Forces Nominal Tensile Force
220 kgf | 484 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
3000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
