Ornit 4.8mm Dome Blind Rivet, 35.0mm Body Length
Ornit 4.8mm Dome Blind Rivet, 35.0mm Body Length
SKU:OPE-e658a9
Sturdy Ornit Dome Blind Rivet for secure fastening in industrial projects.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Ornit 4.8mm Dome Blind Rivet, 35.0mm Body Length
$129.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm Dome Blind Rivet, 35.0mm Body Length
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your industrial projects with this Ornit Dome Blind Rivet. Made from Aluminum Alloy AA 5052, its 4.8mm diameter and 35.0mm length ensure secure fastening. With a low-carbon steel mandrel and zinc-plated finish, it offers excellent shear and tensile strength. Meet institutional demands with its compliance with Federal/DoD procurement standards, GSA requirements, and FAR regulations.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
35.0 mm | 1.378 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.3 mm | 0.366 in
Nominal Dimensions Head Thickness
1.30 mm | 0.051 in
Nominal Dimensions Mandrel Diameter
2.61 mm | 0.103 in
Nominal Dimensions Maximum Grip Range
30.0 mm | 1.181 in
Nominal Dimensions Minimum Grip Range
25.0 mm | 0.984 in
Nominal Forces Nominal Shear Force
150 kgf | 330 lbf
Nominal Forces Nominal Tensile Force
220 kgf | 484 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
