Ornit 4.8mm Steel Dome Head Rivet
Ornit 4.8mm Steel Dome Head Rivet
SKU:STE-4083ce
Versatile and durable 4.8mm steel dome head rivet for secure fastening needs. Made of low carbon steel with a zinc plated chromium VI free finish.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Ornit 4.8mm Steel Dome Head Rivet
$59.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm Steel Dome Head Rivet
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.8mm Steel Dome Head Rivet is a versatile and durable fastener designed for various applications. With a body length of 17.0mm and a multi-grip function, this rivet offers secure fastening solutions for interior main cabin, side frame, and securing rail needs. Made of low carbon steel with a zinc plated chromium VI free finish, it meets high tensile and shear force requirements with a nominal shear force of 450kgf and nominal tensile force of 390kgf.
Product Specifications
Applications Automotive Application
InteriorThe U-Fix is a highly versatile purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of purposes. Commonly used to secure components within the vehicle.
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Length
17.0 mm | 0.669 in
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Diameter
4.8 mm | 3/16 in
Technical Specs Drillhole Size
4.9 mm | 0.193 in
Technical Specs Head Diameter
9.8 mm | 0.386 in
Technical Specs Head Style
Dome
Technical Specs Head Thickness
1.45 mm | 0.057 in
Technical Specs Mandrel Diameter
2.9 mm | 0.114 in
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
Technical Specs Maximum Grip Range
12.0 mm | 0.472 in
Technical Specs Minimum Grip Range
5.5 mm | 0.216 in
Technical Specs Nominal Shear Force
450 kgf | 990 lbf
Technical Specs Nominal Tensile Force
390 kgf | 858 lbf
