Ornit 4.8mm U-Fix Aluminum Steel X-Large Head Rivet
Ornit 4.8mm U-Fix Aluminum Steel X-Large Head Rivet
SKU:UFI-51c3f3
Highly versatile Ornit 4.8mm U-Fix Aluminum Steel Rivet for secure fastening in automotive and trailer applications.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Ornit 4.8mm U-Fix Aluminum Steel X-Large Head Rivet
$99.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm U-Fix Aluminum Steel X-Large Head Rivet
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.8mm U-Fix Aluminum Steel X-Large Head Rivet is a versatile, high-quality fastener designed for various applications. With a unique multi-grip feature, it ensures secure fastening in automotive and trailer settings. Made from durable Aluminum Alloy ALmg 2.5 with a Zinc Plated Chromium (Cr) VI Free finish, this rivet offers exceptional strength and longevity. With a nominal shear force of 159 kgf and a nominal tensile force of 240 kgf, it surpasses industry standards for reliability and performance.
Product Specifications
Applications Automotive Application
InteriorThe U-Fix is a highly versatile purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of purposes. Commonly used to secure components within the vehicle.
Nominal Dimensions Body Length
15.1 mm | 0.594 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
15.85 mm | 0.624 in
Nominal Dimensions Head Thickness
1.75 mm | 0.069 in
Nominal Dimensions Mandrel Diameter
2.8 mm | 0.110 in
Nominal Dimensions Maximum Grip Range
11.1 mm | 0.437 in
Nominal Dimensions Minimum Grip Range
4.8 mm | 0.189 in
Nominal Forces Nominal Shear Force
159 kgf | 350 lbf
Nominal Forces Nominal Tensile Force
240 kgf | 528 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
3000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel
