Ornit 4.8mm x 16.0mm Closed End Blind Rivet
Ornit 4.8mm x 16.0mm Closed End Blind Rivet
SKU:CLO-65b9a2
High-quality Ornit 4.8mm x 16.0mm Closed End Blind Rivet for durable and reliable fastening.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Ornit 4.8mm x 16.0mm Closed End Blind Rivet
$49.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm x 16.0mm Closed End Blind Rivet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your riveting projects with the Ornit 4.8mm diameter and 16.0mm body length closed end blind rivet. Made from high-quality aluminum alloy (AA 5052) with a black phosphate finish on the low carbon steel mandrel, this rivet ensures reliable fastening. With a nominal shear force of 224 kgf and a nominal tensile force of 316 kgf, it meets stringent durability requirements. Perfect for industrial and institutional applications.
Product Specifications
Nominal Dimensions Body Length
16.0 mm | 0.630 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.5 mm | 0.374 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
2.6 mm | 0.102 in
Nominal Dimensions Maximum Grip Range
11.0 mm | 0.433 in
Nominal Dimensions Minimum Grip Range
9.5 mm | 0.374 in
Nominal Forces Nominal Shear Force
224 kgf | 492.8 lbf
Nominal Forces Nominal Tensile Force
316 kgf | 695.2 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
