Ornit 4.8mm x 18mm Dome Blind Rivet
Ornit 4.8mm x 18mm Dome Blind Rivet
SKU:OPE-bd9f8f
Secure connections with Ornit 4.8mm x 18mm Dome Blind Rivet. Durable aluminum construction, ideal for various applications.
Regular price
$75.99
Regular price
Sale price
$75.99
Unit price
per
Initiate Order
Ornit 4.8mm x 18mm Dome Blind Rivet
$75.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm x 18mm Dome Blind Rivet
$75.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.8mm x 18mm Dome Blind Rivet is a high-quality fastening solution ideal for various applications. Crafted from Aluminum Alloy to AA 5052 with a Zinc Plated Chromium VI Free finish, this rivet offers exceptional durability. It features a 4.8mm diameter, 18.0mm body length, and can withstand a nominal shear force of 150kgf and tensile force of 220kgf. With a Dome head style and low carbon steel SAE 1006-1022 mandrel, this rivet ensures secure and long-lasting connections.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
18.0 mm | 0.709 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.3 mm | 0.366 in
Nominal Dimensions Head Thickness
1.30 mm | 0.051 in
Nominal Dimensions Mandrel Diameter
2.61 mm | 0.103 in
Nominal Dimensions Maximum Grip Range
13.0 mm | 0.512 in
Nominal Dimensions Minimum Grip Range
11.0 mm | 0.433 in
Nominal Forces Nominal Shear Force
150 kgf | 330 lbf
Nominal Forces Nominal Tensile Force
220 kgf | 484 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (2.5 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
