Ornit 4.8mm x 20.0mm Closed End Blind Rivet
Ornit 4.8mm x 20.0mm Closed End Blind Rivet
SKU:CLO-73b587
High-strength Ornit 4.8mm x 20.0mm rivet for secure and durable fastening.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Ornit 4.8mm x 20.0mm Closed End Blind Rivet
$59.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm x 20.0mm Closed End Blind Rivet
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior fastening with the Ornit 4.8mm x 20.0mm Closed End Blind Rivet. Crafted from Aluminum Alloy (AA 5052) for durability, this rivet with a black phosphate finish ensures secure connections. With a shear force rating of 224 kgf and a tensile force rating of 316 kgf, it meets stringent quality standards. Ideal for a grip range of 13.0mm to 16.0mm, this rivet guarantees reliable performance in a wide range of applications.
Product Specifications
Nominal Dimensions Body Length
20.0 mm | 0.787 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.5 mm | 0.374 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
2.6 mm | 0.102 in
Nominal Dimensions Maximum Grip Range
16.0 mm | 0.630 in
Nominal Dimensions Minimum Grip Range
13.0 mm | 0.512 in
Nominal Forces Nominal Shear Force
224 kgf | 492.8 lbf
Nominal Forces Nominal Tensile Force
316 kgf | 695.2 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
3000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
