Ornit 4.8mm x 40.0mm Open End Peel Blind Rivet
Ornit 4.8mm x 40.0mm Open End Peel Blind Rivet
SKU:OPE-e78bb5
High-quality Ornit 4.8mm x 40.0mm Blind Rivet for secure and durable fastening in industrial applications.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Ornit 4.8mm x 40.0mm Open End Peel Blind Rivet
$59.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm x 40.0mm Open End Peel Blind Rivet
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.8mm Diameter and 40.0mm Body Length Open End Peel Blind Rivet are expertly crafted to meet the stringent demands of industrial applications. Constructed from high-quality Aluminum Alloy, this rivet boasts exceptional durability. The zinc-plated Chromium VI Free Mandrel ensures secure fastening, with a nominal shear force of 200 kgf. Ideal for a variety of materials, this rivet provides a reliable and sturdy joint every time.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Nominal Dimensions Body Length
40.0 mm | 1.575 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
5.2 mm | 0.205 in
Nominal Dimensions Head Diameter
9.3 mm | 0.366 in
Nominal Dimensions Head Thickness
1.30 mm | 0.051 in
Nominal Dimensions Mandrel Diameter
2.61 mm | 0.103 in
Nominal Dimensions Maximum Grip Range
33.0 mm | 1.299 in
Nominal Dimensions Minimum Grip Range
26.0 mm | 1.024 in
Nominal Forces Nominal Shear Force
200 kgf | 440 lbf
Nominal Forces Nominal Tensile Force
200 kgf | 440 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (3.5-5.0 mg) to AA 5056 /5154
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
Peel
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
