Ornit 4.8mm x 8.0mm Closed End Blind Rivet
Ornit 4.8mm x 8.0mm Closed End Blind Rivet
SKU:CLO-dd6912
Premium Ornit 4.8mm x 8.0mm Blind Rivet for secure and reliable fastening. Compliant with Federal/DoD standards.
Regular price
$49.99
Regular price
Sale price
$49.99
Unit price
per
Initiate Order
Ornit 4.8mm x 8.0mm Closed End Blind Rivet
$49.99
Quantity: 1
Claim Your Seller Account
Ornit 4.8mm x 8.0mm Closed End Blind Rivet
$49.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 4.8mm Diameter and 8.0mm Body Length Closed End Blind Rivet is a premium fastening solution crafted from Aluminum Alloy AA 5052 with a black phosphate steel mandrel. Ideal for industrial applications, this rivet ensures a secure grip range of 1.0mm to 3.5mm, withstanding nominal shear forces of 492.8 lbf and tensile forces of 695.2 lbf. Its precise dimensions, including a 4.9mm drill size and 9.5mm head diameter, guarantee strong, reliable joints. Compliant with Federal/DoD procurement standards and FAR regulations, this blind rivet is a trusted choice for professionals in various industries.
Product Specifications
Nominal Dimensions Body Length
8.0 mm | 0.315 in
Nominal Dimensions Diameter
4.8 mm
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
9.5 mm | 0.374 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
2.6 mm | 0.102 in
Nominal Dimensions Maximum Grip Range
3.5 mm | 0.138 in
Nominal Dimensions Minimum Grip Range
1.0 mm | 0.039 in
Nominal Forces Nominal Shear Force
224 kgf | 492.8 lbf
Nominal Forces Nominal Tensile Force
316 kgf | 695.2 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (5.0 mg) to AA 5052
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Mandrel Finish
Black Phosphate
Technical Specs Mandrel Material
Low Carbon Steel SAE 1006-1022
