Ornit 6.4mm Steel Dome Head Rivet
Ornit 6.4mm Steel Dome Head Rivet
SKU:STE-d701b2
Highly versatile Ornit 6.4mm steel rivet with 14.5mm body length, ideal for various applications. Corrosion-resistant zinc plating chromium (Cr) VI free finish.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Ornit 6.4mm Steel Dome Head Rivet
$45.99
Quantity: 1
Claim Your Seller Account
Ornit 6.4mm Steel Dome Head Rivet
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit 6.4mm Steel Dome Head Rivet is a versatile and durable fastener designed for various applications including interior cabin, side frames, securing rails, and trailer tail installations. With a body length of 14.5mm, this low carbon steel rivet offers a secure grip range from 1.5mm to 7.5mm. It meets stringent zinc plating chromium (Cr) VI free finish standards, ensuring corrosion resistance and longevity. The Ornit rivet's nominal shear force of 700 kgf and tensile force of 420 kgf make it a reliable choice for heavy-duty use.
Product Specifications
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Length
14.5 mm | 0.571 in
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
2000
Technical Specs Diameter
6.4 mm | 1/4 in
Technical Specs Drillhole Size
6.7 to 6.9 mm | 0.263 to 0.271 in
Technical Specs Head Diameter
13.0 mm | 0.512 in
Technical Specs Head Style
Dome
Technical Specs Head Thickness
3.0 mm | 0.118 in
Technical Specs Mandrel Diameter
4.17 mm | 0.164 in
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
Technical Specs Maximum Grip Range
7.5 mm | 0.295 in
Technical Specs Minimum Grip Range
1.5 mm | 0.059 in
Technical Specs Nominal Shear Force
700 kgf | 1540 lbf
Technical Specs Nominal Tensile Force
420 kgf | 924 lbf
