The Ornit OR-Bolt Stainless Steel 100 Degree Countersunk Head Rivets are engineered for supreme durability and reliability. Crafted from AISI 304 Austenitic Stainless Steel, these rivets offer exceptional corrosion resistance and long-lasting strength. With precise nominal dimensions and forces, they ensure secure fastening in a wide range of applications. Perfect for industrial, construction, and institutional projects seeking top-tier riveting solutions.
Product Specifications
Nominal Dimensions Body Length
16.6 mm | 0.654 in
Nominal Dimensions Diameter
6.5 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.62 to 6.9 mm | 0.260 to 0.271 in
Nominal Dimensions Head Diameter
9.8 mm | 0.386 in
Nominal Dimensions Head Thickness
2.00 mm | 0.079 in
Nominal Dimensions Mandrel Diameter
4.0 mm | 0.157 in
Nominal Dimensions Maximum Grip Range
12.1 mm | 0.476 in
Nominal Dimensions Minimum Grip Range
3.2 mm | 0.126 in
Nominal Forces Nominal Shear Force
1193 kgf | 2630 lbf
Nominal Forces Nominal Tensile Force
1060 kgf | 2335 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Austenitic Stainless Steel American Iron and Steel Institute (AISI) 304
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
2000
Technical Specs Head Style
100 Degree Countersunk
Technical Specs Mandrel Finish
Natural
Technical Specs Mandrel Material
Austenitic Stainless Steel American Iron and Steel Institute (AISI) 304
