Ornit OR-Peel 25.0mm Dome Head Self-Piercing Rivets
Ornit OR-Peel 25.0mm Dome Head Self-Piercing Rivets
SKU:ORP-3f570d
Ornit OR-Peel 25.0mm Dome Head Rivets: Strong, durable self-piercing rivets for aerospace, automotive, and construction applications.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Ornit OR-Peel 25.0mm Dome Head Self-Piercing Rivets
$45.99
Quantity: 1
Claim Your Seller Account
Ornit OR-Peel 25.0mm Dome Head Self-Piercing Rivets
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit OR-Peel 25.0mm Dome Head Self-Piercing Rivets are engineered for secure fastening applications in aerospace, automotive, and construction industries. Crafted from Aluminum Alloy (ALmg 3.0/5.0) with a Zinc Coated Chromium (Cr) VI Free mandrel, these rivets provide exceptional strength and corrosion resistance. With a nominal shear force of 250 kgf and a nominal tensile force of 320 kgf, they ensure reliable performance under extreme conditions. The rivets have a drill/hole size range of 6.8 to 7.0mm, a head diameter of 12.0mm, and a body length of 25.0mm, making them ideal for a wide range of gripping requirements.
Product Specifications
Nominal Dimensions Body Length
25.0 mm | 1.0 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.8 to 7.0 mm | 0.268 to 0.276 in
Nominal Dimensions Head Diameter
12.0 mm | 0.472 in
Nominal Dimensions Head Thickness
1.80 mm | 0.071 in
Nominal Dimensions Mandrel Diameter
3.6 mm | 0.142 in
Nominal Dimensions Maximum Grip Range
10.0 mm | 0.394 in
Nominal Dimensions Minimum Grip Range
6.0 mm | 0.237 in
Nominal Forces Nominal Shear Force
250 kgf | 551 lbf
Nominal Forces Nominal Tensile Force
320 kgf | 706 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 3.0/5.0)
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Coated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
