The Ornit OR-Peel 30.0mm Body Length Self Piercing Rivets are expertly crafted with an Aluminum Alloy body and a Carbon Steel mandrel, ensuring durability and performance. With a Dome Head design and a natural finish, these rivets offer a secure grip range from 6.0mm to 15.0mm, capable of withstanding up to 250 kgf shear force and 320 kgf tensile force. Ideal for a wide range of applications, these rivets meet stringent government procurement standards, making them a reliable choice for institutional buyers.
Product Specifications
Nominal Dimensions Body Length
30.0 mm | 1.200 in
Nominal Dimensions Diameter
6.4 mm | 1/4 in
Nominal Dimensions Drillhole Size
6.8 to 7.0 mm | 0.268 to 0.276 in
Nominal Dimensions Head Diameter
12.0 mm | 0.472 in
Nominal Dimensions Head Thickness
1.80 mm | 0.071 in
Nominal Dimensions Mandrel Diameter
3.6 mm | 0.142 in
Nominal Dimensions Maximum Grip Range
15.0 mm | 0.591 in
Nominal Dimensions Minimum Grip Range
6.0 mm | 0.237 in
Nominal Forces Nominal Shear Force
250 kgf | 551 lbf
Nominal Forces Nominal Tensile Force
320 kgf | 706 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy (ALmg 3.0/5.0)
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
1000
Technical Specs Head Style
Dome
Technical Specs Mandrel Finish
Zinc Coated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
