Ornit Steel-Fix X-Large Head Rivet 9.0mm
Ornit Steel-Fix X-Large Head Rivet 9.0mm
SKU:STE-35b615
Ornit Steel-Fix X-Large Head Rivet, 9.0mm: Premium low carbon steel rivet with zinc-plated finish, ideal for industrial use.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Ornit Steel-Fix X-Large Head Rivet 9.0mm
$24.99
Quantity: 1
Claim Your Seller Account
Ornit Steel-Fix X-Large Head Rivet 9.0mm
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit Steel-Fix X-Large Head Rivet in 9.0mm size is a premium fastening solution designed for industrial and automotive applications. Made of low carbon steel with a zinc-plated chromium VI free finish, this rivet provides exceptional strength and vibration resistance. With a nominal shear force of 450kgf and nominal tensile force of 390kgf, it ensures reliable performance. Ideal for thin-sheet materials, this rivet meets stringent quality standards, making it a trusted choice for your projects.
Product Specifications
Applications Automotive Application
Window FrameThe Steel Fix fastener is ideal for thin-sheet materials and providing a strong, vibration resistant joint. This solution was tailored made for a leading, American vehicle manufacturer.
Nominal Dimensions Body Length
9.0 mm | 0.354 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
15.85 mm | 0.624 in
Nominal Dimensions Head Thickness
1.90 mm | 0.075 in
Nominal Dimensions Mandrel Diameter
2.9 mm | 0.114 in
Nominal Dimensions Maximum Grip Range
4.0 mm | 0.157 in
Nominal Dimensions Minimum Grip Range
1.5 mm | 0.059 in
Nominal Forces Nominal Shear Force
450 kgf | 990 lbf
Nominal Forces Nominal Tensile Force
390 kgf | 858 lbf
Technical Specs Body Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Body Material
Low Carbon Steel
Technical Specs Brands
Ornit | Steel-Fix
Technical Specs Carton Quantity
3000
Technical Specs Head Style
Extra Large
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Carbon Steel
