Ornit U-Fix 3.2mm Aluminum Steel Rivet
Ornit U-Fix 3.2mm Aluminum Steel Rivet
SKU:UFI-006ddf
Ornit 3.2mm Aluminum Steel Rivet - High-quality, durable large head rivet for industrial applications. Zinc-plated steel mandrel, aluminum alloy body. Secure grip range of 5.5mm-9.5mm.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Ornit U-Fix 3.2mm Aluminum Steel Rivet
$99.99
Quantity: 1
Claim Your Seller Account
Ornit U-Fix 3.2mm Aluminum Steel Rivet
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit U-Fix 3.2mm Aluminum Steel Large Head Rivet is a reliable and durable fastening solution suitable for a wide range of applications. Crafted from high-quality Aluminum Alloy ALmg 2.5 with a natural finish, this rivet ensures secure connections. The low carbon steel mandrel, zinc-plated with chromium (Cr) VI Free finish, provides excellent strength and corrosion resistance. With a large head design and precise dimensions, including a 3.2mm diameter and 12.7mm body length, this rivet offers a strong grip ranging from 5.5mm to 9.5mm. Meeting stringent technical specs and nominal forces, this rivet is ideal for industrial, construction, and automotive use.
Product Specifications
Nominal Dimensions Body Length
12.7 mm | 0.500 in
Nominal Dimensions Diameter
3.2 mm | 1/8 in
Nominal Dimensions Drillhole Size
3.3 mm | 0.130 in
Nominal Dimensions Head Diameter
8.25 mm | 0.325 in
Nominal Dimensions Head Thickness
1.0 mm | 0.039 in
Nominal Dimensions Mandrel Diameter
1.81 mm | 0.071 in
Nominal Dimensions Maximum Grip Range
9.5 mm | 0.374 in
Nominal Dimensions Minimum Grip Range
5.5 mm | 0.217 in
Nominal Forces Nominal Shear Force
75 kgf | 165 lbf
Nominal Forces Nominal Tensile Force
104 kgf | 230 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
7000
Technical Specs Head Style
Large Head
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel
