Ornit U-Fix Aluminum Steel Snap Head Rivet, 4.8mm x 15.1mm
Ornit U-Fix Aluminum Steel Snap Head Rivet, 4.8mm x 15.1mm
SKU:UFI-d1d4de
Versatile Ornit U-Fix Snap Rivet, 4.8mm x 15.1mm, for secure fastening in automotive applications.
Regular price
$59.99
Regular price
Sale price
$59.99
Unit price
per
Initiate Order
Ornit U-Fix Aluminum Steel Snap Head Rivet, 4.8mm x 15.1mm
$59.99
Quantity: 1
Claim Your Seller Account
Ornit U-Fix Aluminum Steel Snap Head Rivet, 4.8mm x 15.1mm
$59.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Ornit U-Fix Aluminum Steel Snap Head Rivet boasts exceptional durability with its Aluminum Alloy ALmg 2.5 body and Zinc Plated Chromium VI Free mandrel, suitable for various applications. With a diameter of 4.8mm and a body length of 15.1mm, this rivet offers a secure grip range from 4.8mm to 11.1mm. Ideal for automotive use and robust enough to withstand nominal shear force up to 159kgf and tensile force up to 240kgf.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Applications Automotive Application
The U-Fix is a highly versatile purpose-built fastener, featuring an excellent multi-grip function ideal for a variety of purposes. Commonly used to secure components within the vehicle.
Nominal Dimensions Body Length
15.1 mm | 0.594 in
Nominal Dimensions Diameter
4.8 mm | 3/16 in
Nominal Dimensions Drillhole Size
4.9 mm | 0.193 in
Nominal Dimensions Head Diameter
8.6 mm | 0.339 in
Nominal Dimensions Head Thickness
1.65 mm | 0.065 in
Nominal Dimensions Mandrel Diameter
2.8 mm | 0.110 in
Nominal Dimensions Maximum Grip Range
11.1 mm | 0.437 in
Nominal Dimensions Minimum Grip Range
4.8 mm | 0.189 in
Nominal Forces Nominal Shear Force
159 kgf | 350 lbf
Nominal Forces Nominal Tensile Force
240 kgf | 528 lbf
Technical Specs Body Finish
Natural
Technical Specs Body Material
Aluminum Alloy ALmg 2.5
Technical Specs Brands
Ornit
Technical Specs Carton Quantity
4000
Technical Specs Head Style
Snap Head
Technical Specs Mandrel Finish
Zinc Plated Chromium (Cr) VI Free
Technical Specs Mandrel Material
Low Carbon Steel
