Parker MARSA Soft Seat Relief Valve - Factory Set
Parker MARSA Soft Seat Relief Valve - Factory Set
SKU:VAL-1fdc07
Dependable MARSA Soft Seat Relief Valve - factory set for precision gas control in high-pressure systems. Ideal for zero-leakage applications.
Regular price
$329.99
Regular price
Sale price
$329.99
Unit price
per
Initiate Order
Parker MARSA Soft Seat Relief Valve - Factory Set
$329.99
Quantity: 1
Claim Your Seller Account
Parker MARSA Soft Seat Relief Valve - Factory Set
$329.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Parker MARSA Soft Seat Relief Valve, factory set at pressures ranging from 1,500 psi to 15,000 psi, offers dependable venting of gases in critical pressure gas systems. With a soft seat design ensuring bubble-tight sealing, repeatable pop-off, and exceptional cycle life, this precision valve is ideal for applications where zero leakage is essential. Designed for MPI™ Specialty Valves and Filters, this valve provides reliable performance in temperatures from -50ºF to 400ºF. With its preciseness and durability, the MARSA Soft Seat Relief Valve is a must-have component for applications requiring high-pressure gas control.
Product Specifications
Dimensions A
10.62 in
Dimensions Back Pressure Max
500 psi | 34 bar
Dimensions Connection
MPI™ to FNPT
Dimensions Orifice Diameter
.156 in
Dimensions Pressure Rating Max
5000 psi | 345 bar
Dimensions Pressure Rating Min
1500 psi | 103 bar
Dimensions Repair Kits
R9MARSA-5K-2507
Dimensions Size
9/16 x 3/4
Specifications Caution
Parker Relief Valves are preset and factory sealed. Warranty is voided if seal is broken by customer. Maximum system operating pressure should not exceed 90% of relief valve set pressure. Pressures in excess of this value may cause weepage resulting in damage to plug and seat. Care should be taken when locating a relief valve within a piping system to keep the relief valve as far from the pump as possible. Certain pumps create an end-of-stroke spike in pressure that is not detectable by common instrumentation. These spikes could cause premature failure of the relief valve.
