Parker MARSA Soft Seat Relief Valve - Factory Set
Parker MARSA Soft Seat Relief Valve - Factory Set
SKU:VAL-60118c
Reliable Parker MARSA Soft Seat Relief Valve designed for precision gas system venting. Factory set for optimal performance.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Parker MARSA Soft Seat Relief Valve - Factory Set
$129.99
Quantity: 1
Claim Your Seller Account
Parker MARSA Soft Seat Relief Valve - Factory Set
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Parker MARSA Soft Seat Relief Valve, factory set for precision performance, offers reliable venting of gases at pressures ranging from 1,500 psi to 15,000 psi. Designed with a soft seat for bubble-tight sealing and a repeatable pop-off, this valve ensures zero leakage in pressure gas systems. With a superior cycle life compared to metal seat relief valves, the MARSA valve meets critical applications where accuracy and reliability are paramount. Please note that this valve is not suitable for liquid nitrogen or liquid carbon dioxide relief applications.
Product Specifications
Dimensions A
10.62 in
Dimensions Back Pressure Max
500 psi | 34 bar
Dimensions Connection
MPI™ to FNPT
Dimensions Orifice Diameter
.156 in
Dimensions Pressure Rating Max
15000 psi | 1035 bar
Dimensions Pressure Rating Min
10000 psi | 690 bar
Dimensions Repair Kits
R9MARSA-15K-2507
Dimensions Size
9/16 x 3/4
Specifications Caution
Parker Relief Valves are preset and factory sealed. Warranty is voided if seal is broken by customer. Maximum system operating pressure should not exceed 90% of relief valve set pressure. Pressures in excess of this value may cause weepage resulting in damage to plug and seat. Care should be taken when locating a relief valve within a piping system to keep the relief valve as far from the pump as possible. Certain pumps create an end-of-stroke spike in pressure that is not detectable by common instrumentation. These spikes could cause premature failure of the relief valve.
