Parker Pneumatic SK-200 Series Solenoid Valve

Name: Parker Pneumatic SK-200 Series Solenoid Valve
Brand: Jamieson Equipment Co., Inc.
SKU: AIR-e0de9a
Price: 149.99 USD
Availability: OutOfStock

SKU:AIR-e0de9a

The Parker Pneumatic SK-200 Solenoid Valve: high performance, easy maintenance, CSA-approved.

$149.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Parker Pneumatic SK-200 Series Solenoid Valve is a high-performance solution designed for both consumer and institutional applications. Featuring a plug-in design for easy maintenance and installation, this valve ensures minimal downtime with its interchangeable solenoids and locking manual overrides. The encapsulated coil enables low-power consumption and extended lifespan. With a wide range of port sizes available and field convertibility to external pilot supply, this valve offers design flexibility and efficiency. Precision engineering with synthetic rubber O-ring seals and a precision ground spool ensures superior wear resistance and precise operation. CSA-approved for general purpose use, this valve meets the highest quality and safety standards.

Product Specifications

Specifications Duty Cycle

Standard Service Solenoid or Remote

Specifications Enclosure Class

Standard (NEMA 1 & 12) or Remote

Specifications Lead Length

19 in

Specifications Manufacturer

Parker Pneumatic

Specifications Nominal Cv

5.5

Specifications Operator

Solenoid

Specifications Operator Option

Solenoid w/Jct. Box & Light (120VAC, 24VDC) & Locking Override

Specifications Service

Lubricated

Specifications Size

3/4" NPT Inlet, Cyl. & Exh.

Specifications Type

Double

Specifications Valve Style

Direct Pipe Ported

Specifications Voltage

120 VAC, 60 Hz

Parker Pneumatic SK-200 Series Solenoid Valve
