Parker Pneumatic Valvair II 4-Way Solenoid Valves

Name: Parker Pneumatic Valvair II 4-Way Solenoid Valves
Brand: Jamieson Equipment Co., Inc.
SKU: AIR-602b11
Price: 199.99 USD
Availability: OutOfStock

SKU:AIR-602b11

Premium Parker Pneumatic Valvair II 4-way solenoid valves for industrial applications. High Cv, versatile installation, and precise pressure control options.

$199.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Parker Pneumatic Valvair II Series 4-way, 5-port, 2-position, plug-in solenoid valves are designed for robust industrial applications like concrete aggregate plants and steel mills. With flow factors up to 12 Cv, these valves offer versatility in installation as single inline, subbase, or on segmented manifolds. Featuring operators from air piloted to solenoid air piloted, these valves are field-convertible for external pilot operated service. The valves boast urethane O-rings, Nituf-coated aluminum spools for improved lubrication retention and low-friction operation, and the option to add sandwich pressure regulators for precise air pressure control. Ideal for 5/2 and 5/3 functions, the Valvair II Series ensures reliable performance in various industrial settings.

Product Specifications

Specifications Duty Cycle

Standard Service Solenoid or Remote

Specifications Enclosure Class

Standard (NEMA 1 & 12) or Remote

Specifications Manufacturer

Parker Pneumatic

Specifications Nominal Cv

4.8

Specifications Operator

Solenoid

Specifications Operator Option

Solenoid w/Light (120VAC, 24VDC) & Locking Override

Specifications Service

Lubricated Non-Lubricated Service

Specifications Size

3/8" Basic

Specifications Type

Single

Specifications Valve Style

Plug -In

Specifications Voltage

120 VAC, 60 Hz
