Parker Pneumatic Valvair II 5-Port Solenoid Valve

Name: Parker Pneumatic Valvair II 5-Port Solenoid Valve
Brand: Jamieson Equipment Co., Inc.
SKU: AIR-f4c59e
Price: 289.99 USD
Availability: OutOfStock

SKU:AIR-f4c59e

Robust and versatile solenoid valve with up to 12 Cv flow factors, dynamic urethane o-rings, and Nituf coated aluminum spools for improved lubrication and low friction operation.

$289.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Parker Pneumatic Valvair II Series Solenoid Valve is a robust, versatile solution ideal for a wide range of industrial applications. With flow factors reaching up to 12 Cv, this valve can be flexibly installed as a single inline, subbase valve, or on segmented manifolds. Featuring dynamic urethane o-rings and Nituf coated aluminum spools, it ensures improved lubrication retention and low friction operation. This valve offers various operators from solenoid air to remote pilot operated, with options for non-locking and locking manual overrides. Additionally, the inclusion of sandwich pressure regulators allows precise air pressure control at each valve application point.

Product Specifications

Specifications Duty Cycle

Standard Service Solenoid or Remote

Specifications Enclosure Class

Standard (NEMA 1 & 12) or Remote

Specifications Manufacturer

Parker Pneumatic

Specifications Nominal Cv

4.8

Specifications Operator

Remote

Specifications Operator Option

Solenoid w/Light (120VAC, 24VDC) & Non-Locking Override

Specifications Service

Lubricated Non-Lubricated Service

Specifications Size

1" Basic

Specifications Type

Single

Specifications Valve Style

Plug -In

Specifications Voltage

12 VDC
