Parker Pneumatic Valvair II Series Solenoid Valve

Name: Parker Pneumatic Valvair II Series Solenoid Valve
Brand: Jamieson Equipment Co., Inc.
SKU: AIR-d346bd
Price: 309.99 USD
Availability: OutOfStock

SKU:AIR-d346bd

Enhance industrial efficiency with the versatile Parker Pneumatic Valvair II Series Solenoid Valve, ideal for demanding applications. Experience superior performance and easy integration.

$309.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Parker Pneumatic Valvair II Series Solenoid Valve is a top-tier solution designed for robust industrial applications like concrete aggregate plants and steel mills. With flow factors reaching up to 12 Cv, this valve offers exceptional performance and versatility. It can be effortlessly configured as a single inline or subbase valve for point-of-use setups, or integrated into segmented manifolds for centralized operations. Featuring a range of operators from air piloted to solenoid air piloted, and the option for direct conduit or junction box electrical connections, this valve is a versatile choice. Its field conversion capability from internal to external pilot operated service, along with non-lube operation suitability, ensure efficient and low-friction performance. The dynamic urethane o-rings with an off-center parting line, combined with Nituf coated and hardened aluminum spools, provide superior lubrication retention and operation. Additionally, the valve supports the integration of sandwich pressure regulators for precise air pressure control at each application point.

Product Specifications

Specifications Duty Cycle

Standard Service Solenoid or Remote

Specifications Enclosure Class

Standard (NEMA 1 & 12) or Remote

Specifications Lead Length

19 in | 72 in

Specifications Manufacturer

Parker Pneumatic

Specifications Nominal Cv

4.8

Specifications Operator

Solenoid

Specifications Operator Option

Solenoid w/Jct. Box & Locking Override

Specifications Service

Lubricated Non-Lubricated Service

Specifications Size

3/8" NPT Inlet & Cyl. 1/2" NPT Exh.

Specifications Type

Single

Specifications Voltage Options

Parker Pneumatic Valvair II Series Solenoid Valve
