Parker Pneumatic Valvair II Series Solenoid Valves

Name: Parker Pneumatic Valvair II Series Solenoid Valves
Brand: Jamieson Equipment Co., Inc.
SKU: AIR-27fe07
Price: 249.99 USD
Availability: OutOfStock

SKU:AIR-27fe07

Robust Parker Pneumatic Valvair II Solenoid Valves with high flow factor and versatile installation options for industrial applications.

$249.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Parker Pneumatic Valvair II Series Solenoid Valves are designed for robust industrial applications in environments like concrete aggregate plants and steel mills. With a high flow factor of up to 12 Cv, these 4-way, 5-port valves offer versatility in installation as single inline, subbase, or manifold configurations. Featuring a range of operators from air-piloted to solenoid air-piloted and options for direct conduit or junction box electrical connections, these valves can be field converted for external pilot operation. The valves boast dynamic urethane o-rings, Nituf-coated aluminum spools, and off-center parting lines for enhanced lubrication retention and low-friction performance. Additionally, they can accommodate sandwich pressure regulators for precise air pressure control at each valve. Ideal for 5/2 and 5/3 functions, these valves meet various industry certifications and offer temperature, pressure, and solenoid operation within specified ranges.

Product Specifications

Specifications Duty Cycle

Continuous Service Solenoid

Specifications Enclosure Class

Standard (NEMA 1 & 12) or Remote

Specifications Manufacturer

Parker Pneumatic

Specifications Nominal Cv

4.8

Specifications Operator

Remote

Specifications Operator Option

Solenoid w/Light (120VAC, 24VDC) & Locking Override

Specifications Service

Lubricated Non-Lubricated Service

Specifications Size

1" Basic

Specifications Type

Single

Specifications Valve Style

Plug -In

Specifications Voltage

12 VDC

Parker Pneumatic Valvair II Series Solenoid Valves
