PC-159 100% Solids Epoxy System
PC-159 100% Solids Epoxy System
SKU:PC1-2da657
Discover the PC-159 100% Solids Epoxy System - a reliable, cost-effective encapsulant meeting UL 94V0 standards for superior performance.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
PC-159 100% Solids Epoxy System
$39.99
Quantity: 1
Claim Your Seller Account
PC-159 100% Solids Epoxy System
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The PC-159 100% Solids Epoxy System is a versatile, low-cost encapsulant designed for general-purpose use. With a mix ratio of 1:1 by volume, this room temperature cure epoxy offers outstanding moisture resistance and is machine dispensable. Meeting UL 94V0 standards, it boasts flexural strength of 9,500 psi, making it ideal for various applications requiring durability and reliability.
Product Specifications
Cure Schedule 0
Room temperature cure at 75 °F with full properties after 24 hours | To accelerate cure, allow 2 hours at room temperature, then 2 hours at 125 °F.
Mixing Instructions 0
Pre-mix Part A and Part B separately. Then measure 1:1 by volume (A to B). Mix thoroughly scraping the sides and bottom of the container. Evacuate and then pour into mold or cavity.
Properties Cured Coefficient Of Thermal Expansion
56 x 10-6
Properties Cured Dielectric Constant According To American Socie
3.5
Properties Cured Heat Distortion Point
80 ºC
Properties Cured Thermal Conductivity
6 BTU-in/(ft2)(hr)(°F)
Properties Cured Water Absorption
0.08 %
Properties Uncured Color
Black (Part A) | Neutral (Part B)
Properties Uncured Shelf Life At 70 F
12 m
Properties Uncured Viscosity At 25 C Cps American Society For Te
7 to 10,000 (Part A) | 5 to 7000 (Part B)
Specifications Compressive Strength According To American Societ
9,000 psi
Specifications Dielectric Strength According To American Society
420 V/mil
Specifications Dissipation Factor According To American Society
0.03
Specifications Flexural Strength According To American Society F
9,500 psi
Specifications Mixed Viscosity According To American Society For
5 to 8000 cps
Specifications Mix Ratio By Volume
1:1
Specifications Pot Life At 25 C 100 Gram G
90 min
Specifications Shore D Hardness According To American Society Fo
82 duro
Specifications Specific Gravity
1.4 | 1.4 (Part A) | 1.5 | 1.5 (Part B)
Specifications Standards
UL 94V0
Specifications Tensile Elongation According To American Society
6 %
Specifications Tensile Strength According To American Society Fo
8500 psi
Specifications Type
General Purpose Epoxies
Specifications Viscosity According To American Society For Testi
5 to 7000 cps | 7 to 10,000 cps
Specifications Volume Resistivity Viscosity At 25 C According To
1 x 1015 ohm-cm
