PC 3.5 Flange Mount Female Connectors with Interchangeable Transition Pins

Name: PC 3.5 Flange Mount Female Connectors with Interchangeable Transition Pins
Brand: C. W. Swift & Associates, Inc.
SKU: PC3-2592e3
Price: 29.99 USD
Availability: OutOfStock

SKU:PC3-2592e3

Enhance connectivity with PC 3.5 Flange Mount Female Connectors - durable, precise, and compliant for institutional needs.

$29.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

Experience premium connectivity with our PC 3.5 Flange Mount Female Connectors featuring interchangeable transition pins for optimal performance. Built to meet demanding institutional standards, these connectors offer an impedance of 50 Ohms, RF leakage of over 100db, and a wide frequency range of DC to 33GHz. With a durable stainless steel body, beryllium-copper contacts, and silicone rubber gaskets, they ensure reliable connections in harsh environments. Trust in the durability of over 500 matings, temperature resilience from -85 to 194 degrees F, and compliant design for secure panel mounting. Upgrade your connectivity with these precision connectors.

Product Specifications

Specifications Body Material

stainless steel

Specifications Cable Entries

brass

Specifications Centre Contacts

beryllium-copper, hardened

Specifications Centre Contact Resistance M Ohms

Specifications Configuration

panel mounted

Specifications Connection

female

Specifications Connector Series

PC 3.5

Specifications Contact Captivation Lbs

>6.1

Specifications Coupling Nut Retention Force Lbs

>60.7

Specifications Dielectic Withstanding Voltage Sea Level V Rms

750/1000

Specifications Durability Matings

>500

Specifications Flange Type

square

Specifications Frequency Ghz

DC...33

Specifications Gaskets

silicone rubber

Specifications Impedance Ohms

Specifications Insulation Resistance M Ohms

>50000

Specifications Outside Contact Resistance M Ohms

Specifications Packaging

single

Specifications Rf Leakage Db

>100

Specifications Support Beads

polystyrene, crosslinked

Specifications Temperature Range Degrees F

-85 to 194

Specifications Working Voltage Sea Level V Rms

<250/<335
