PC 3.5 Precision Straight Adaptors Within-Series
PC 3.5 Precision Straight Adaptors Within-Series
SKU:PC3-6211b9
Maximize connectivity with PC 3.5 Precision Straight Adaptors. Impedance 50 Ohms, RF Leakage >100db, durable stainless steel body.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
PC 3.5 Precision Straight Adaptors Within-Series
$29.99
Quantity: 1
Claim Your Seller Account
PC 3.5 Precision Straight Adaptors Within-Series
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance your connectivity with these high-performance straight adaptors for PC 3.5 series connectors. With an impedance of 50 Ohms, RF Leakage exceeding 100db, and a durable stainless steel body, these adaptors ensure reliable connections in demanding environments. Meeting stringent standards for impedance, RF leakage, and durability, these adaptors are ideal for both consumer and institutional applications.
Product Specifications
Specifications Body
stainless steel
Specifications Body Material
stainless steel
Specifications Cable Entries
brass
Specifications Centre Contacts
beryllium-copper, hardened
Specifications Centre Contact Resistance M Ohms
<3
Specifications Configuration
straight
Specifications Connection
female-female
Specifications Connector Series
PC 3.5
Specifications Contact Captivation Lbs
>6.1
Specifications Coupling Nut Retention Force Lbs
>60.7
Specifications Dielectic Withstanding Voltage Sea Level V Rms
750/1000
Specifications Durability Matings
>500
Specifications Frequency Ghz
DC...33
Specifications Gaskets
silicone rubber
Specifications Impedance Ohms
50
Specifications Insulation Resistance M Ohms
>50000
Specifications Outside Contact Resistance M Ohms
<2
Specifications Packaging
single
Specifications Rf Leakage Db
>100
Specifications Support Beads
polystyrene, crosslinked
Specifications Temperature Range Degrees F
-85 to 194
Specifications Vswr 18 26 Ghz F
1.15
Specifications Vswr Dc 18 Ghz F
1.08
Specifications Working Voltage Sea Level V Rms
<250/<335
